Wi-Fi Trainer Kit
TECHNICAL SPECIFICATION :
802.11 b/g/n protocol.
8- bit single channel DAC
Wi-Fi direct (P2P), soft-AP.
Two 6V relays with isolated O/Ps.
Integrated TCP/IP protocol stack.
All interrupts available on header.
Integrated TR switch, balun , LNA, power amplifier and matching network.
16X2 LCD display
8 I/Ps from DIP switches.
Integrated PLL, regulators and power management units.
8 O/Ps available on LED's
+19.5dBm output power in 802.11b mode.
Four multiplexed 7-segment displays
Integrated temperature sensor.
4 push buttons for interrupt study
Supports antenna diversity.
Windows based driver software for programming.
Power down leakage current of < 10uA.
4x4 Matrix Hex Keypad
Integrated low power 32 bit CPU could be used as application processor.
Stepper and D.C Motor Interface
Buzzer Section
SDIO 2.0, SPI, UART.
IR Transmitter/ Receiver
STBC, 1x1 MIMO, 2x1 MIMO.
LDR (Light Dependent Resistor).
A-MPDU & A-MSDU aggregation & 0.4us guard interval.
LM- 35 Temperature Sensor
Wake up and transmit packets in < 2ms.
DTMF
Standby power consumption of < 1.0mW(DTIM3).
RF Receiver
Nuvoton W78E052D C with ISP features
In- circuit Programming and serial communication through PC.
8-bit-8 channel ADC with I/Ps from multi-turns potentiometers.
FUNCTIONS :
Understanding The Wi-Fi System
Communication Using Wi-Fi
How Wi-Fi works
Reading An Input on LCD
Controlling The Appliances Using Wi-Fi communication
